| Product Name |
Portable Card Dispenser |
| Print Method |
Seaory E300 |
| Print Technology |
Print Resolution
|
| Print Module |
300dpi × 300dpi，300dpi × 600dpi，300dpi × 1200dpi |
| Printing Module (Top Module) |
Dual-sided printing |
Duai-sided printing & Indented Characters |
| Indented Characters |
Not Supported |
CVV2 code(10 digits from 0 to 9) |
| Embossing & Indenting Module(Bottom Module) |
Embossing/indenting wheel: support 75 characters, including10 blank characters.
Embossing characters: Farrington 7B (0-9), OCR-B upper-case alphabet & digits & symbols(0-9, A-Z，& / . , ' -).
Foil stamping: support gold/silver or other colors as you choose.
|
| Print Speed |
Monochrome printing: 4s per card(single-sided)
Full-color YMCKO printing: 20s per card(single-sided),42s per card(dual-sided)
Different combination of Monochrome/ full-color YMCKO/Magnetic stripe/Chip card/ Embossing/ Indenting/Foil stamping: 27s to 120s according to the standard issuing time of bank/credit cards
|
Monochrome printing: 4s per card(single-sided)
Full-color YMCKO printing: 20s per card(single-sided)，42s per card(dual-sided)
Different combination of Monochrome/ full-color YMCKO/Magnetic stripe/Chip card/ Embossing/ Indenting/Foil stamping: 27s to 120s according to the standard issuing time of bank/credit cards
|
| Input hopper capacity |
100 cards (0.76mm) |
| Reject tray capacity |
The top and bottom modules have one reject tray for each with capacity: 30 cards(0.76mm) |
| Card Material |
PVC cards, Composite cards(PVC+PET), rewritable cards |
| Card Size |
ISO CR80(53.98mm×85.60mm) |
| Card Thickness |
0.2mm—1.10mm |
| Operating System |
Windows，Android，Linux, or Windows+Android |
| Hardwares |
All the hardwares necessary to the corresponding operating system |
| Front Screen |
10.1 inch LCD touch screen, support handwriting, up-down flipping |
| Back Screen(Optional) |
10.1 inch LCD touch screen, detachable |
| Optional Multi-function Module |
1.RFID card reading: read identification information from ID cards
2.PIN pad module: support Triple DES encryption, password input
3.Fingerprint module: support fingerprint acquisition, feature processing, fingerprint comparison, etc.
4.Binocular camera: facial recognition, face liveness detection(optional), facial comparison(optional), etc.
5.Environmental camera: monocular camera for environmental monitoring
6.Chip card encoding module: contactless & contact dual interface encoding, ISO7816/ISO14443 TYPE A/B; PC/SC
7.Magnetic stripe card encoder: support ISO7811 hico&Loco 1/2/3 tracks encoding
8.Barcode scanner: support barcode, QR code reading
9.WIFI: Dual-band 2.4G/5G, IEEE 802.11b/g/n; network speed: 300Mbps
10.Bluetooth: bluetooth 4.0 or above (as you choose), transmission distance 6-10 meters
11.Remote communication module: 4G or 5G remote communication module (as you choose), acess Internet by plugging in a SIM card
|
| Indicator Lights |
LED light bar: 3 colors to choose (blue/green/red). Indicator lights near the output slot of the card printing module(top module): green.
Indicator lights near the output slot of the embossing & indenting module(bottom module): green. Developer package supplied, support adjusting lightness level and flashing.
|
| Software |
According to operation system and customer needs, all the related development kits are supplied, including demos and code examples.
|
| Power Supply |
Power adapter，AC100-240V 50/60Hz， DC24V 15A
|
| Dimensions & Weight |
625mm(L)×406mm(W)×494.5mm(H)，27.2kg(with 2 panels and 2 touch screens)
|
| Security |
Locks in the top module: protect cards,ribbons, 4G/5G chips and reject tray from being stolen.
Locks in the bottom module: protect indenting ribbons, foil stamping ribbons, and reject tray from being stolen.
|
| Operating environment |
1. Regular Running Temp: 15℃-30℃(59-86℉), 20%-65% RH non-condensing>
2. Lowest/ Highest Running Temp: 0℃(32℉)/40℃(104℉), 20% to 65% RH non-condensing
|
| Storage Environment |
Temp.: -5℃-70℃(23-158℉), 20% to 70% RH non-condensing and ventilation environment |
| Certifications |
CCC，FCC，CE，ROHS, etc. (Pending)
|
